SCM 52 Bar Cutting Machine
SCM 52 Bar Cutting Machine Details
Not every construction site needs the same cutting setup. When reinforcement work involves different bar sizes and repeated cutting, the machine needs to match the actual workload. We manufacture and supply the SCM 52 Bar Cutting Machine in Ahmedabad, Gujarat, as a semi-automatic machine for regular steel bar cutting work. The model has a 3.7 kW (5 HP) motor, 60 strokes per minute capacity and a 550 kg machine weight.
Made for Repeated Steel Bar Cutting
The SCM 52 uses a double-stage helical gearbox to reduce speed and support smoother transmission to the cutting mechanism. The gears are heat treated and precision ground. This arrangement is made to support smooth movement and reduce unnecessary wear during regular operation.
A dynamically balanced flywheel helps keep vibration and operating noise lower while the bars are being cut. The cutting blades are made from special hardened steel and are designed for cutting both smaller and larger diameter steel rods.
Construction Details That Support Daily Use
- Semi-automatic machine operation
- Double-stage helical gearbox design
- Heat-treated and precision-ground helical gears
- Dynamically balanced flywheel
- Special hardened steel cutting blades
- Custom DOL starter with over-voltage and under-voltage protection
- Reverse rotation prevention
- Sheet metal components for protection against rust
- Wheels for easier movement on the construction site
- Design focused on rugged construction and easier maintenance
SCM 52 Specification Table
| Model | SCM 52 |
|---|---|
| Voltage | 380 V |
| Capacity | 60 strokes per minute |
| Power | 3.7 kW (5.0 HP) |
| Motor Speed | 2900 RPM |
| Automation Grade | Semi Automatic |
| Weight | 550 kg |
Bar Capacity for Different Grades
Bar cutting capacity changes with bar diameter and steel grade. The supplied SCM 52 capacity chart covers FE 500, FE 500D, FE 550D and FE 500S. The table below shows the number of bars for each listed diameter.
| Bar Grade | 40 mm | 36 mm | 32 mm | 25 mm | 20 mm | 16 mm | 12 mm | 10 mm | 8 mm |
|---|---|---|---|---|---|---|---|---|---|
| FE 500 | - | 1 | 1 | 1 | 2 | 2 | 3 | 4 | 5 |
| FE 500D | - | 1 | 1 | 1 | 2 | 2 | 3 | 3 | 4 |
| FE 550D | - | 1 | 1 | 1 | 2 | 2 | 3 | 3 | 4 |
| FE 500S | - | 1 | 1 | 1 | 2 | 2 | 3 | 3 | 4 |
We manufacture and supply the SCM 52 Bar Cutting Machine from Ahmedabad, Gujarat, for construction and reinforcement applications. If you're checking a machine for a particular bar size or grade, share those details with us. We'll provide the relevant information so you can compare the machine with your site requirement before making a decision.
