SCM 55 Rebar Cutting Machine
Call Now
WhatsApp
AvailabilityOut Of Stock
CategoryBar Cutting Machine
Payment MethodsCash, COD, DirectDebit
Rated 0.0/5 based on 0 customer review
5
0
0%
4
0
0%
3
0
0%
2
0
0%
1
0
0%
SCM 55 Rebar Cutting Machine Details
Features:-
- “SKYMAC” Bar Cutting Machine’s Design Adheres to Safety Standards.
- Each part in this premium model of cutting machine is designed with advanced software with a goal to make the machine rugged, stronger & maintenance free.
- We Use of double stage helical gearbox design, thus reducing speed & improving the life of blades vastly.
- All gear are suitable heat treatment process with precision Granding helical gear in gears which are Smooth
- The machine is fitte with Dynamically balancing flywheel. Thus, it gives minimum vibration and less
- Noise while cutting bars. This ensures a long life of Machine’s moving parts.
- This cutting blades are made from special hardened steel & designed to cut small and big diameter steel rods.
- All models are provide with specious custom model Dol starter with built in additional safety for over and under voltage Protection and reverse rotation prevention.
- Bar cutting machine are specially designed with sheet metal components for longer life and protection against rust.
- These machines are provided with wheels for easy movement on site
Specifications:-
| Brand | Skymac |
| Usage/Application | Bar Cutting |
| Material | TMT Bar |
| Motor Capacity | 5.5 Kw ( 7.5 hp) |
| Weight | 775 kg |
| Model Name/Number | SCM 55 |
| RPM | 2900 RPM |
| Oil Volume | 4.5 Ltr |
| Surface Finishing | Painted |
| Stroke | 60 Per Minute |
| Dimension | 1225 x 1025 x 770 MM |
SCM 55 Rebar Cutting Machine Capacity Chart Details:-
| Bar Spec | Bar Dia | ||||||||
| Dia of Bar in mm | 40 | 36 | 32 | 25 | 20 | 16 | 12 | 10 | 8 |
| No. of Bars of TMT FE 500 (TENSILE STRENGTH 50 Kg.mm2) | 1 | 1 | 1 | 2 | 2 | 3 | 5 | 7 | 8 |
| No. of Bars of TMT FE 500D (TENSILE STRENGTH 60 Kg.mm2) | 1 | 1 | 1 | 2 | 2 | 3 | 5 | 7 | 8 |
| No. of Bars of TMT FE 550-FE 600 (TENSILE STRENGTH 70 Kg.mm2) | 1 | 1 | 1 | 2 | 2 | 3 | 5 | 6 | 8 |
| No. of Bars of TMT FE 550-FE 600 (TENSILE STRENGTH 70 Kg.mm2) | 1 | 1 | 1 | 2 | 2 | 3 | 5 | 6 | 8 |
