SCM 55 Bar Cutting Machine
SCM 55 Bar Cutting Machine Details
When bar cutting becomes a regular part of construction work, the machine needs to handle repeated cycles without making the job unnecessarily complicated. We manufacture and supply the SCM 55 Bar Cutting Machine in Ahmedabad, Gujarat, for TMT bar cutting applications. This model comes with a 5.5 kW (7.5 HP) motor, 60 strokes per minute and a 775 kg machine weight.
Designed for Regular TMT Bar Cutting
The SCM 55 uses a double-stage helical gearbox design. It helps reduce speed through the transmission system and supports longer blade life. The gears are heat treated and precision ground for smooth operation.
A dynamically balanced flywheel helps reduce vibration and noise during cutting. The cutting blades are made from special hardened steel and are designed for cutting small and large diameter steel rods. Wheels are provided for easier movement of the machine around the site.
Construction Features at a Glance
- Design developed with attention to safety requirements
- Double-stage helical gearbox
- Heat-treated and precision-ground helical gears
- Dynamically balanced flywheel
- Special hardened steel cutting blades
- Custom DOL starter with over-voltage and under-voltage protection
- Reverse rotation prevention
- Sheet metal components for protection against rust
- Wheels for easier site movement
- Painted surface finish
SCM 55 Machine Details
| Brand | SKYMAC |
|---|---|
| Model Name / Number | SCM 55 |
| Usage / Application | Bar Cutting |
| Material | TMT Bar |
| Motor Capacity | 5.5 kW (7.5 HP) |
| Motor Speed | 2900 RPM |
| Stroke | 60 per minute |
| Weight | 775 kg |
| Oil Volume | 4.5 Litre |
| Surface Finish | Painted |
| Dimensions | 1225 x 1025 x 770 mm |
Cutting Capacity for Common TMT Grades
The actual cutting capacity depends on the bar diameter and TMT grade. The SCM 55 capacity chart covers FE 500, FE 500D and FE 550-FE 600 grades. The figures below show the listed number of bars for each diameter.
| TMT Bar Grade | 40 mm | 36 mm | 32 mm | 25 mm | 20 mm | 16 mm | 12 mm | 10 mm | 8 mm |
|---|---|---|---|---|---|---|---|---|---|
| FE 500 | 1 | 1 | 1 | 2 | 2 | 3 | 5 | 7 | 8 |
| FE 500D | 1 | 1 | 1 | 2 | 2 | 3 | 5 | 7 | 8 |
| FE 550-FE 600 | 1 | 1 | 1 | 2 | 2 | 3 | 5 | 7 | 8 |
| FE 550-FE 600 | 1 | 1 | 1 | 2 | 2 | 3 | 5 | 7 | 8 |
We manufacture and supply the SCM 55 Bar Cutting Machine from Ahmedabad, Gujarat, for construction and TMT bar cutting work. If you're planning to use the machine for specific bar diameters or grades, share your requirement with us. We'll provide the relevant machine details and capacity information for your work.
